What's New in Revit 2022

April 07, 2021 3 min read

What's New in Revit 2022

Chaos Vantage

This is the release you have been waiting for. The new Revit 2022 brings more effective design to documentation workflows, improved interoperability for project teams across all stages of design, and a raft of design productivity enhancementsthat will raise the quality of both your design and your life.
These are the areas where the improvements are making a big impact.

Connectivity

Autodesk is constantly  improving the way project teams can use Revit to work across software platforms, disciplines, and industries. You can now link McNeel Rhinoceros® 3DM files directly into Revit 2022, and a new round-trip workflow between Revit and FormIt Pro has also been introduced.
Similarly, Inventor 2022 assemblies can be exported as RVT files, enabling direct linking into your Revit projects, and building a greater between architectural design and architectural fabrication.

Tag and Schedule

In Revit 2022 you’ll find many improvements to schedules, annotations and tags. These upgrades make project setup and authoring more precise, fast, and less error-prone. Rotated tags, flexible revision numbering, spot slopes and elevations, and the display of grids in 3D views all hone the capabilities of Revit as a tool for capturing and communicating design intent.

Tools for Everybody

Revit 2022 has the latest updates to the Generative Design and Route Analysis tools, giving you better support for geometry and more informed design decision-making.  Engineers of all stripes will benefit from the improved documentation tools. Structural engineers also see enhancements for steel connections and a host of rebar improvements, further expanding a broad set of capabilities. MEP engineers and fabricators benefit from schedule upgrades that make it easier to document design intent in Revit. The Design to Fabrication tool has been enhanced to provide a smoother, more consistent workflow. Mechanical systems analysis sees significant improvements.

Here's the complete list of bullet points for Revit's new features and enhancements relative to INTEROPERABILITYDOCUMENTATION EFFICIENCY and DESIGN PRODUCTIVITY.

INTEROPERABILITY

  • Native 2D PDF Export 
  • Link Rhino 3DM Files 
  • 3D Sketch and Send to Revit with FormIt Pro 
  • Import FormIt as a CAD Format 
  • IFC4 Certification for Architecture and Structure 
  • IFC Performance and Quality Improvements 
  • Link Inventor Assemblies as Revit Models 
  • Nameable Reference Geometry 
  • Persistent Tags for DirectShapes 
  • 2D Shared Views 
  •  Open Cloud Model from File Menu

DOCUMENTATION EFFICIENCY

  • Enable Scheduling of Worksets
  • Schedule Enhancements
  • Export Schedules to CSV by Default
  • Multiple Values Indication
  • Tag Improvements
  • Multi-category Tag for All Taggable Categories
  • Link Tag Re-hosting
  • Dimension Prefix/Suffix
  • Revision Numbering Flexibility Enhancements
  • Spot Slopes and Elevations on Ramps
  • Show Wall Core Only in Plan Views
  • Grids in 3D Views
  • Phase Parameters in View Filters
  • Improved Default Color Fill Scheme
  • Multi-select Visibility/Graphics Overrides Filters
  • Preserve Callouts When Deleting Parent Views
  • Maintain Annotation Orientation
  • Fixes to Key MEP Documentation
  • Auto-shading in Two-column Panel Schedules

DESIGN PRODUCTIVITY

  • Enhanced RPCs in Realistic Views
  • Enhanced RPCs in Realistic Views
  • Route Analysis Tools
  • Infrastructure Enhancements
  • Rename Default Shared Site
  • Fabrication Improvements
  • Systems Analysis
  • Family Category Improvements
  • Move Rebar in a Set
  • Model Rebar Using the Real Bar Diameter
  • Rebar Placement by Two Points
  • Select Shape Code for Custom Bent Free Form Rebar
  • Remember Settings when Placing Rebar
  • Rebar Performance Improvements
  • Associate Steel Connections with Profile Sizes
  • Category Lists Sorting Improvement
  • Category Lists Sorting Improvement
  • Load Autodesk Family

Connect with our Autodesk expert scott@novedge.com or call 866 362 8970 ext.705  if you have questions about Revit 2022, the Architecture Engineering Construction Collection or if you want to take advantage of Autodesk 0% financing.
