ZBrush Tip: Steady Stroke: Stabilize Linework and Control Pattern Stamping

Sharpen line work and stamp patterns with confidence by enabling Steady Stroke (LazyMouse) to stabilize your hand and control spacing.

Why use Steady Stroke

• Clean, jitter-free strokes for panel lines, seams, and inlays.
• Evenly spaced pattern repeats with alphas for ornament, stitches, and scales.
• Consistent pressure and depth for passes you can reliably reproduce.

Quick setup

• Open Stroke palette > LazyMouse and toggle LazyMouse on (hotkey: L).
• Set LazyRadius to 10–25 for medium details; increase for long arcs and pinstripes.
• Use LazySmooth (8–20) to average micro jitters without losing intent.
• For repeated stamps along a path, enable LazyStep (0.3–1.0) to define the distance between dabs.
• With Freehand stroke type, adjust Stroke > Spacing to 0–10 to avoid competing with LazyStep.

Straight and guided passes

• Toggle Backtrack (Stroke > LazyMouse) and choose Line for perfect straight strokes.
• Enable Snap to Track so your cursor sticks to the track for repeatable passes over the same line.
• For gentle curves, try Backtrack > Path to follow your initial guide motion, then refine with Snap to Track.

Pattern strokes that read clean in renders

• Pick a brush (Standard, DamStandard, Chisel) and load a tiling alpha.
• Activate Brush > Modifiers > Roll to roll the alpha continuously along the stroke.
• Balance LazyStep vs Roll Distance to set pattern cadence without overlaps.
• Stabilize depth with Brush > Depth > Imbed and keep Z Intensity steady for uniform relief.
• Use Symmetry or Radial Symmetry to multiply clean, consistent motifs.

Speed and consistency boosters

• Press 1 for Replay Last to quickly echo a stroke; try Replay Last Relative for surface-aware repeats.
• Save a custom brush preset that bakes in your LazyMouse, Roll, and intensity settings.
• Pair with Backface Masking (Brush > Auto Masking) to prevent through-surface artifacts on thin shells.

Troubleshooting

• Laggy feel: Reduce LazyRadius or LazySmooth; hide dense subtools to keep FPS high.
• Uneven spacing: Don’t stack controls—use either Spacing or LazyStep as the primary cadence driver.
• Wobbly starts/ends: Begin each pass a bit before the visible area and exit after, trimming in post if needed.
• Over-polished edges: Lower LazySmooth or switch to HPolish/Trim Dynamic after laying the stroke.
