LWCAD 2020 for LightWave is a top set of add-on modeling plugins for LightWave 3D. Core of this package contains a complete set of standard CAD tools with the most advanced osnap engine. It equips your favorite modeling program with the countless features normally available only in expensive CAD applications.
LWCAD 2020 for LightWave contains revolutionary features such as a real-time curve booleans or real-time polygons drilling which are absolutely unique in the industry, as well as a new set of archiviz tools which are specially designed for creating architecture. It allows users to create a complex building in a few minutes. These new features will push you into another modeling dimension.
With the new MeshTR engine, you can look forward to many new and updated tools.
Features
NURBS curve 2
-
- Latest version is fully compatible with previous curve types from LWCAD 4.5 and older
- Older curve types are automatically converted when object is loaded
- Lines and curve segments can be joined into a single poly-curve
- Closed curves are supported
- Smart mesh is a unified geometry system of polygons and NURBS surfaces
- The basic idea of this system, is to connect polygons and nurbs surfaces into homogeneous objects
- Polygons and surfaces are connected with shared edges which are defined by curves or lines
- Level of detail of these shared edges are identical for both sides of connected surfaces or polygons
- Smart selection system is incorporated into LWCAD since version 5.0
- The purpose of this system, is to unify and simplify behavior of all LWCAD edit tools when using on smart mesh. LWCAD 2020 for LightWave uses the smart selection system in all tools listed in the Smart Edit section
- It is based on selection handles which can also have adjustable parameters
- Selection handles are created from geometry
- Adjustable handles are created from geometry or as a combination of existing handles
- LWCAD since version 2 contains a complete snap engine which is fully integrated into all of the LWCAD tools. Snap modes are adjustable through the "Snap Panel"
- Universal Coordinate System, or UCS, allows you to create a user-defined adjustable workplane
- BG Layers Snap allows you to snap to geometry in background layers
- Polygon Slice: all curve primitives also have the ability to slice polygons. Tool must be applied by clicking on a polygon and then slice mode is enabled with pol button
- Polygon Boolean: all polygon-based primitive tools can use real-time polygon Boolean. Polygonal Boolean operations preserve UV maps on objects
- Curve Boolean: all curve primitive tools can use real-time curve Boolean functions. Boolean operations are calculated between objects created with tools and the rest of the scene geometry that lies on the same UCS workplane as the current tool. Boolean operations only work with LWCAD NURBS curves
- NURBS Boolean: NURBS boolean is not available yet. It is planned feature for one of future releases. As a manual solution 'Add point' and 'Offset' functions can be used
Tools
- Window
- New parametric tool for creating windows. Object can be created from curves, polygons or NURBS.
- using new pop-up preset system for custom sizes and parameters
- basic shapes types (rectangle, arch, triangle)
- custom inner-outer framing and sill
- custom edges and corners
- Edge To Railing
- New parametric tool for creating railings from selection on existing geometry.
- using selection of curve segments, polygon edges or nurbs surface edges
- using new pop-up preset system
- railing is assembled from five optional layers : rails, sub-rails, posts, sub-posts and fillings
- all profiles can be created with curves or extruded rectangle or circle profile.
- Railing
- New railing tool based on Line Tool.
Stairs
- New railing pop-preset, build railing presets from rail tools directly into stair object
- Profile
-
- polygons and NURBS mode are synchronized
- new handles placement modes: Segment Ends, Corner Ends, Rail Ends
- new mode for align profile to ground
- new parameter show profile csys
- Rect UV & Quad UV
- New 'Rect UV Linked' parameter allows to enable-disable linking or rectangle size with UV map size.
- Rectangle,Box,Windoor, Rect Roof, Rect Stair & Wall
- new pop-up presets for size dimensions
- Knife
- new optional multi-blade mode, with pop-up presets for blades distances
Trial Download
LWCAD Trial Software Download
Test LWCAD before you make your purchasing decision.Specs
Installation Requirements
In order to work properly, your copy of LWCAD 2020 for LightWave requires:
|
|
