Workflow: Reverse Engineering of Nozzle Prototype | QUICKSURFACE

July 07, 2026 1 min read

Autodesk Fusion 360

Video From YouTube: QUICKSURFACE




QuickSurface demonstrates a reverse-engineering workflow for a handmade nozzle, transforming 3D scan data into a clean CAD-ready model. The process includes reviewing scanned geometry, establishing symmetry planes, and extracting key reference features to recreate the rough welded pipe prototype. The base fitting is rebuilt with precision, while the curved nozzle path is reconstructed to match the original form. Cleanup and surface optimization prepare the model for accurate CAD export and downstream manufacturing. The workflow highlights practical strategies for handling noisy scans, maintaining design intent, and achieving manufacturable results using QuickSurface tools. Detailed chapter markers guide viewers through each essential step.
