How to Conditionally Format Your Results with Text Boxes | Mathcad Prime Advanced Controls Series

December 19, 2024 1 min read

Autodesk Fusion 360

Video From YouTube: Mathcad, a PTC Technology




Discover the versatility of Text Boxes in PTC Mathcad Prime 10 and how they can be utilized for advanced conditional formatting of results. This tutorial provides a comprehensive guide on creating and customizing Text Boxes, emphasizing their unique ability to visually represent data outcomes. Learn how to effectively change the background color of these controls to highlight design check results, such as using red for failures and green for successes. Viewers are encouraged to download the accompanying example worksheet, which includes a conditional formatting script for further adaptation and experimentation in their own projects. Enhance your data presentation with these powerful tools.

If you like this content please subscribe to the Mathcad YouTube Channel
