Urbano Visio 90 is a pipe network data management add-in for Autodesk Civil 3D, with smart features for pipe and structure selection, editing and analysis. It supports a modern BIM workflow, improves productivity and decreases design time.
Civil engineers and experts contributed their ideas and experience to help create a software that offers solutions to real-life problems. Urbano Visio 90 is the right tool to help you find and inspect important design data, use smart data selections and filters, apply editing changes with precision and quickly create data tables and reports.
Urbano Visio 90 is available for Civil 3D 2017 – 2021.
Convert Civil 3D pipe network data to Property Set Data & export to IFCSelect any pipe network data (e.g. pipe diameter, slope, structure type) and copy it to Property Set Data. You can copy object data and label expressions as well. When exporting the pipe network to an .ifc file the property set data get exported as well, creating a data-rich 3-D model.
Quick pipe trench volume calculation for Civil 3DCreate your own simple trench configuration using parameters like trench side angles, bottom width and bedding type and thickness. To calculate select the pipe network, surface and trench configuration. You can also define multiple excavation zones according to excavation depth. After running the calculation, the results will be written to property set data and to an MS Excel report that includes volumes and pipe lengths.
Pipe invert editing in Civil 3D profile viewsEdit existing pipe inverts directly in profile views! Select a profile view and the starting and ending structure to review the values for depth, elevation and slope. Input a new slope and the depth and elevation will be recalculated. Or, input the numerical value or pick the depth or elevation in the drawing and the slope will be recalculated. You can also set a standard drop to all structures in the selected range.
Pipe invert drawing in Civil 3D profile viewsDraw pipe inverts directly in profile views! You can set visual drawing aids (min and max depth below terrain), and also set the preferred slope step e.g. 1 %. To start drawing just click on any structure. While drawing you can also set precise numerical values for pipe elevation, depth below terrain & slope.
Add, move, delete structure in Civil 3D profile viewsAdd, move and delete structures directly in profile views. All three options allow you to set the function behavior (e.g. keep existing slope), select and pick directly in the profile view and input numerical values for extra precision.
Convert 2D/3D lines/polylines to a Civil 3D pipe networkSelect source elements from the drawing, set appropriate pipes and structures from the part list and convert the elements to an existing pipe network. You can convert 2D/3D lines, polylines and polylines with arcs. If a source polyline connects to a segment rather than a vertex, the program will create a structure. You can also choose to apply rules to the converted elements.
Interactive pipe and structure editing for Civil 3DInspect pipes and structures using any data included in custom configuration tooltips. Selecting a pipe or structure enables you to use editing functions to move structures and their alignment simultaneously, swap parts, insert a new structure, set the start/end elevation or pipe cover and set the pipe slope. In addition to the interactive editing functions, any editable tooltip data can be changed as well.
Apply pipe/structure rules to a Civil 3D pipe networkApply pipe and structure rules to the whole network or a selected network part with a few clicks: just choose one of the available networks, select the elements from the drawing and set the appropriate rules. Selections include pipes, branches, pipe sequence, profile view and whole network.
Hydraulic calculation for Civil 3D gravitational pipe networksQuickly calculate all hydraulic values for the whole network, a network part, a single pipe or even without any pipes. Before running the calculation choose the appropriate formula (Manning or Darcy-Weisbach) and measure unit system (Imperial or Metric). You can automatically dimension pipes using parameters like min. diameter and max. pipe fill percentage. The results are written to property set data.
Learn quicklyEvery program function is documented in the online help and supported with video guides.
In order to work properly, your copy of Urbano Visio 365 — 1-Year Subscription requires:
AutodeskCivil 3DModel in 3D with civil engineering software.
