Home / Datakit / SolidWorks Plugin: CATIA V5 3D to SolidWorks - Data Translator with 1-Year Maintenance

SolidWorks Plugin: CATIA V5 3D to SolidWorks - Data Translator with 1-Year Maintenance

SKU: 4367
MPN: CV5SW + maint.
UPC:---------
Perpetual License
Datakit | SolidWorks Plugin: CATIA V5 3D to SolidWorks - Data Translator with 1-Year Maintenance
Options
885

SolidWorks PlugIn to Translate 3D data from CATIA V5 into SolidWorks. Certified Gold Product by SolidWorks. Includes compulsory annual maintenance

Datakit
Authorized Reseller

$2,729 $2,875 You Save ($146)

As low as $252.43/month with CreditKey CreditKey
Ask for Quote
Talk to our Experts
866 362 8970

Digital
Delivery

Product download information and license key delivered via EMail

Available
in USA + CA

Best Price
Guarantee

Prorated Licenses, Flexible Payments, Custom Orders

SolidWorks Plugin: CATIA V5 3D to SolidWorks Data Translator with 1-Year Maintenance is a plug-in based on the new Datakit API which significantly improves the geometric conversion of native CAD models.

Features

  • Enables accurate and convenient CAD data transfer from CATIA V5 to SolidWorks.
  • Does NOT require a license of CATIA V5.
  • Converts Part and Assembly files :.CATPart and .CATProduct files.
  • Translates ALL 3D data, including CATIA V5 Exact Solids.
  • Data can be filtered based on Entity Type and Visibility.
  • Enables meta data import in SOLIDWORKS.
  • Batch mode process : Batch option or multiple file select (Needs a specific license).
  • Conversion of the features tree (Needs a specific license).
  • Conversion of the graphical presentation of PMI (Product Manufacturing Information) (Option provided as is for free).
  • Certified "gold product" by SolidWorks.
Installing this plug-in will add to SolidWorks imports for CATIA V4 2D, CATIA V5 2D, CATIA V5 3D, CATIA V6 3D, JT and ProE / Creo Parametric 3D. However, you need a license for each desired import.

Specs

Installation Requirements


In order to work properly, your copy of SolidWorks Plugin: CATIA V5 3D to SolidWorks Data Translator with 1-Year Maintenance requires SolidWorks.


Support & Maintenance


SolidWorks Plugin: CATIA V5 3D to SolidWorks Data Translator with 1-Year Maintenance includes a manufacturer's 90-day warranty.

Tags

CATIA Data Translation Solidworks Windows
