SolidWorks Plugin: CATIA V4 & V5 - 2D & 3D Importer/Exporter - Data Translator

Overview

SolidWorks Plugin: CATIA V4 & V5 - 2D & 3D Importer/Exporter Data Translatorenables accurate and convenient CAD data import from:

• CATIA V4 2D (*.model, *.dlv, *.dlv3, *.exp)
• CATIA V4 3D (*.model, *.dlv, *.dlv3, *.exp, *.session)
• CATIA V5 2D (*.CATDrawing)
• CATIA V5 3D (*.CATPart, *.CATProduct)

Exports SOLIDWORKS open document to:

• CATIA V4 3D (*.model)
• CATIA V5 3D (*.CATPart, *.CATProduct)

Specs

Installation Requirements

In order to work properly, your copy of SolidWorks Plugin: CATIA V4 & V5 - 2D & 3D Importer/Exporter Data Translator requires SolidWorks.

Support & Maintenance

Product sales include a 90-days warranty. Additional warranty coverage is available under a separate annual maintenance contract agreement.
