$895 $931 You Save ($36)
Digital Delivery
Available in USA + CA
Best Price Guarantee
Contours
Snapping
Material Stock
Contours Heights
Tool Management
Toolbar Customisation
Toolpath Side and Direction
Snapping Part 1/2
Snapping Part 2/2
SharpCam's Machine Developer - Part 1/2
SharpCam's Machine Developer - Part 2/2
Feature
Description
SharpCam 2.5D
SharpCam 3D
SharpCam 3D Pro
Solid Verification
Advanced Polygon Model based integrated toolpath verification
✔
Pocketing
Advanced pocketing with unlimited number of pockets and islands
Drilling
Drilling, pecking, boring, reaming, tapping, rigid tapping and custom drilling cycles
Thread Milling
Helical Entry/Exit arc and or line
3D Roughing
Z level roughing of Solid/STL Models
Parallel 3D Finishing
Finishing/Semi finishing of Solid/STL Models by means of parallel passes in the XY plane
Z Level 3D Finishing
Finishing/Semi finishing of Solid/STL Models by means of Z level passes
3D Constant Cusp
Creates an equidistant cut pattern on the machining surfaces. The aim is to have a constant distance between each pass so that the cusps created will have the same height
Projected 3D Curves
Project contours onto modelProject radial pattern onto modelProject spiral pattern onto modelProject offset curves from give contour
3D FlatLands
Machine true flat areas of the model with passes that are offset segments of the flat area boundary
3D Pencil
Automatically detects inlaying edges. A single tool path will be created along these edges
Rest Rough/Finish
Machine remaining material left by a previous larger tool
Adaptive roughing strategy
Ensures that the cutting conditions remain almost constant, which offers great improvements compared to conventional constant offset roughing strategies
Pilot Drilling
Specify previous drilling operation to be used for entry points
Gouge Check
Specify Models to be avoided
Material Stock Containment
3D machining is based on supplied Material Stock. Used for pre-cast or pre-machined stock
Silhouette Containment
Limits the machining area by the silhouette of the machining surfaces
Ramping and Lead In-Out
Defines the lead-in motion for the 3D Roughing. Defines lead-in/out motion for all other strategies
Arc Fit
Convert where possible, linear moves to arcs for 3D strategies
Adaptive Feedrate
Automatically adapts the feedrate depending on the tool engagement volume in the material
Explode
Explode model such that each face is a model
Create tool libraries/tool kits with the Tool Manager, edit, copy and move tools
CAD
2D CAD creation
Dimensions
Dimensioning: Smart Linear, Horizontal, Vertical, Aligned, Diameter, Radius, Angle, Coordinate and Note
Rearrange Operations
Operation can be reordered by drag and drop
Entry/Exit
Line and or arc entry/exit, linear and helical ramp entry
Transforms
Move, copy, rotate, mirror and scale contours along with associated toolpaths
Simulation
3D tool simulation. Solid, translucent or wireframe animated tool display
Context Snapping
End, mid, centre, quadrant, tangent, intersection, perpendicular and parallel snapping
Modify Contours
Advanced fillet, trim, extend, split and explode
Text
Create text outlines from fonts installed on the system (TrueType etc). Outlines can then be machined
Follow a Contour
Single line engraving fonts
Create single line text for engraving using SharpCam type fonts.
Sub Routines
Output multiple passes using Sub Routines. i.e. M98 PNNNN for Fanuc, Labels for Heidenhain, or whatever form sub routines take on the control. Reduces program size
Insert
Insert an existing SharpCam file or any supported CAD file into an existing
Extract Geometry from Solid Model
Extract Contours from Face, Extract Contours from Loop and Extract Contours from Edge commands for feature extraction
Align Solid Model
Align model face to XY plane, Align to Edge and Flip Model 180° commands to assist in model orientation
Use defined fonts
Create custom design fonts.
Multi Document Interface
Open unlimited number of Parts within one instance of SharpCam
Cad File Translations
AutoCad - dxf and dwg, stereo lithography - stl
STEP and IGES
Undo/Redo
Unlimited undo/redo
Viewing
Dynamic panning, zooming and rotation with middle mouse button/wheel
Hidden Line
Connection markers help identify hidden lines
Machine Developer
Edit Machine Definitions (post processors) with the Machine Developer using Visual Basic.Net
RS232
Built in RS232 communication
Nc Code Editing
Free Nc code editor with built in RS232 communication - SharpEdit
Calculator
Use any combination of +-/* in an input box to calculate any value
Operation Suppression
Suppression of any/all operations to prevent Nc code generation
Layers
Create and manage layers
Cycle time
Test 'what if' scenarios
Updates
Automatic self-updating to the latest version during allowed period
