rhino.io - Upgrade

SKU: 17072
MPN:---------
UPC:---------
LAUBlab | rhino.io - Upgrade
Options
11

rhino.io: Directly open and save native Rhino 6 files (.3dm) from within Maxon Cinema 4D

LAUBlab
Authorized Reseller

$65

As low as $6.01/month with CreditKey CreditKey
Ask for Quote
Talk to our Experts
866 362 8970

Digital
Delivery

Product download information and license key delivered via EMail

Available
in USA + CA

Best Price
Guarantee

Prorated Licenses, Flexible Payments, Custom Orders




rhino.io is a connection and import/export plugin that lets you directly open and save native Rhino files (3dm) from within MAXON CINEMA. In addition, models that were changed in Rhino can be updated into CINEMA 4D while keeping material assignments and other changes inside CINEMA 4D intact, enabling you to work with Rhino and CINEMA 4D side by side.

Rhino could therefore act as a NURBS plugin for CINEMA 4D, connecting the best of both worlds. Rhino's precise and extensive CAD and NURBS tool set can be combined with CINEMA 4Ds modern and flexible texturing, shading and lighting tools.

Models imported with rhino.io are also ready to use for any high quality 3rd party rendering engine such as VRAYforC4D, Maxwell, Fryrender and more.

Features


rhino.io reads / converts:
NURBS
Rhino NURBS Objects are automatically translated into native, ready to render CINEMA 4D Polygon objects. They use the internal Rhino so called render meshes, which Rhino uses for rendering and stores in each file ones it got shown with OpenGL in view port or rendered. As normal tags store the original NURBS curvature data, they render perfectly smooth in CINEMA 4D.
MESHES
Meshes from Rhino, generated from custom tessellation, native mesh objects, grasshopper, paneling tools or imported from any other 3rd-party application are being transported into native, ready to render CINEMA 4D Polygon objects.
LIGHTS
Any lights set in Rhino will be translated into equivalent CINEMA 4D lights. they can be used further on for visualization with AR, VRAYforC4D, Maxwell, etc
SPLINES
rhino.io imports and translates also poly lines and even NURBS splines. the NURBS splines get auto tessellated on import, as CINEMA 4D has no real NURBS splines. they can be used for further modeling, or as construction help lines.
CAMERAS
Rhino "saved views" / Cameras are also imported. you get the exact same views in CINEMA 4D. not only the active Camera is imported but also all saved views stored in the rhino .3dm file. They come in as native CINEMA 4D Camera Objects (they work also with the VRAY Physical camera tag).
LAYERS
Layers & Groups are a very important part of Rhino modeling. rhino.io imports all Rhino layers & groups, also the nested structures. You can choose if you want to import hidden layers or not. also hide and lock status is translated into CINEMA 4D. You can choose if you want to import the layers as native CINEMA 4D layers, or if you want to import them as groups into Object manager (both can be very handy and useful).
BLOCKS
If you use Rhino Blocks, or if you import an Autocad file via Rhino, rhino.io will also import the blocks correctly, automatically translating them into native CINEMA 4D Instances. This enables new work flow possibilities in combination of Rhino and C4D, the use of blocks becomes a very useful work flow through that feature.
FILE UPDATE
If you have already imported the 3dm file once, and if you change something in Rhino, you can update the file in CINEMA 4D, without the need to load the file anew. Simply use the merge command, and rhino.io will automatically detect the updated parts and only import them. All materials that have been applied will be saved, and no work or changes that have already be done in CINEMA 4D will be lost.
MATERIALS
Rhino Materials on Rhino objects can be imported into CINEMA 4D. Basic attributes like color, transparency, specular, etc are translated into CINEMA 4D material.
CUSTOM MESH
Optionally, Rhino Layer colors are also imported. This can be very useful when you import Rhino layers as Groups. The layer color will be a material tag added to the corresponding layer group, providing a very fast and efficient work flow for visualization.
LAYER COLORS
In Rhino you have the possibility to set a custom per object render mesh attribute. rhino.io is able to read this special Object properly and use it for the CINEMA 4D import. In that way you can easily apply custom tessellation settings to a Rhino object without the need to actually tessellate it into a mesh before export.
Objects, splines, cameras, layers, etc can be also exported back from CINEMA 4D to Rhino. This is useful when you have a geometry in CINEMA 4D, and you want to add details or special geometry in Rhino. rhino.io lets you directly save a 3dm file out of CINEMA 4D.

Specs


Installation Requirements

In order to work properly, your copy of rhino.io requires Rhino v4 and v5, Cinema 4D R19 and R20.
