QUICKSURFACE - Maintenance - Educational License

How it works

Start with a mesh Scan your product with any 3D scanner that can export STL, OBJ or PLY meshes or PTZ point clouds	Convert to CAD Use QUICKSURFACE tolls to reconstruct the free form or parametric CAD surfaces and to remodel them to your needs	Export & use it Export in industry standard STEP or IGES file format to other CAD/CAM packages or use your results for 3D printing or CNC machining

Features

QUICKSURFACE is scan to CAD software for transforming 3D scan meshes from any 3D scanner into CAD models. Equipped with simple yet powerful features you can quickly convert your digitized data into ready to use models. Explore some of the main features.

Scan Data Import Load data from any scanner using the industry standard STL, OB or PLY mesh files. For long range scanners, the data can be imported using PTX file format. Being a 64 bit application allows the user to load any size mesh. For the purposes of manipulation the build-in polygon reduction function allows the user to create a mesh with suitable number of triangles without compromising the quality of the mesh	Interactive selection Simple to use tools to quickly extract areas of interes. Magic wand, brush and free form selection allows the user to identify the areas that represent features or free form surfaces	Primitives extraction Reconstruct quickly planes, cylinders, cones and spheres. Create relations between them as peprendicularity, parallelism and coincidence. You can also create a reference geometries like lines and points for use in align mesh to space operation for correctly positioning the object into the world coordinate system
Symmetry Plane Find a plane of symmetry of the object. Use the analyser to identify the quality of the position of the plane. Fine tune the position with on-screen controls to achieve the best results	Object align Position the object into the world coordinate system using the extracted primitives. The interactive definition of the coordinate system allows the user to adjust the correct orientation of the object	2D Sectioning Interactive sectioning allows the user to extract rerefence points for 2D Sketching. Align the section plane to extracted primitives, CAD faces and even create section interactively on the screen. For the purposes of lofting - the user can also create multiple sections at once
Constrained 2D Sketching Use dimensions and constraints to create accurate sketches like in any other CAD package	3D Sketching, Loft, Sweep surfacing Draw free form curves directly on the reference mesh then create surfaces by standard commands - loft, sweep, pipe. Join the surface or use them in trimming operations	Fit Surface Select area of interest and let the software to approximate the selection with a free form surface. The resulting surface is extended so it is suitable for trimming. The real-time deviation colour map instantly shows the quality of the surface. Automatic option allows the user to create surface as close as possible to the reference mesh
Free Form Modelling Quad surface allows the user to reconstruct free form surface which is not possible with the standard surfacing methods. Proprietary snap-to-mesh technology allows even non-professionals to create shapes in no time - something not available in any other solutions	Real-time deviation analyser Speed optimised real-time distance colour map allows the user to keep everything in control and get the most accurate results	Automatic Surfacing Create surface on organic shapes with just hit of a button. No user interaction required. QUICKSURFACE provides you with one of the best automatic surfacing available today. The algorithm optimises the number of resulting nurb patches to be minimal. The surface quality is G2 everywhere and G1 at extraordinary points
Hybrid parametric modelling Together of being parametric for the standard features, the software allows you to create CAD models as a combination of free form and prismatic features. The user can always get back and modify even the free form surfaces if needed and get the results reconstructed	Triming & Boolean operations Create surfaces or solids by using mutual trim operation or boolean operations on solids. The coloured display and diagnostic tools allow you to identify the issues while performing these operations	Fillet & Chamfer The chamfer and fillet operations provide a realtime analyser. Just drag the arrow to define the fillet radius on the screen and see immediatelly the deviation of the fillets against the reference mesh. And all this in real-time
Deviation Analyser Control the accuracy of your reconstruction with the efficient distance colour map. Compare the CAD model against the reference mesh at any time of your process	Link to other CAD Packages Export reconstructed surfaces or solid models for use in other packages using the industry standard format STEP or IGES.

Why QUICKSURFACE?

Once you have your object scanned, export it from your scanning software as STL, OBJ or PLY mesh or PTX point cloud and load in QUICKSURFACE.
As the software is fully optimized, there is no limitation of the size of the mesh you import. Reduce the number of triangles if needed.
Use QUICKSURFACE's simple and powerful tools to create 2D sketches, extruded and revolved surfaces and free form surfaces. Apply standard CAD operations like trimming, booleans and patterns. Finish your work with adding fillets and chamfers.
Keep control over your work with state of the art deviation control at any time of your work. Create a hybrid model with the best accuracy and design intent.
Once you are ready export as industry standard STEP or IGES file or transfer directly the full parametric tree into SOLIDWORKS.

Compare

Which version of QUICKSURFACE is right for you?
