Mesh2Surfaceis a plug-in for Rhinoceros offering a number of simple but efficient features to optimize the process of converting scanned data to a perfect CAD model.
Mesh2Surface is fully compatible with Rhino5, 6 and 7.
MeshSurface Premium offers all Standard features plus:
Free form Organic modelling
Symmetry based modelling
Snap to Mesh Technology
Real-time tolerancing for free form modelling
Manipulator (gumball) based modelling
Surface quality analysis
PTX Points Import
Organic free form reverse engineering. Simple, efficient, fast.
Automatically create free form surfaces with hit of a button.
Draw curves directly on the mesh to create free form surfaces.
Toleranced 3D Sketch
Keep the quality in control in real time while modelling.
Build surfaces with real-time control.
Extracting planes, cylinders, spheres, revolved and extruded surfaces.
Toleranced based free form surface.
Keep your reverse engineering under control.
Using fitted shapes to align object to world coordinate system.
Automatically split a mesh based on curvature.
Estimate radius of the fillet of a CAD edge from underlying mesh.
Set the shapes to be vertical, horizontal or custom direction.
The video shows how to use the symmetry plane.
In order to work properly, your copy of Mesh2Surface Premium requires:
McNeel Rhino for Windows and Mac Rhino 3D with Grasshopper: The most powerful NURBS 3D CAD Industrial Design and modeling tool with full support from McNeel. Rhino 6.0 license now comes with Grasshopper included.
Proof of Academic Status
Students, Teachers and Professors in Full Time Education
Primary school, secondary school, college, university and career state-accredited school students qualify to order with acceptable form of academic ID. Please provide one of the following:
Dated student ID card OR
Official dated current class schedule
Any state accredited school can order single-user educational licenses or lab licenses on a school purchase order or procurement card.
Sending the Proof
Information regarding where to send your Proof of Educational Status will be automatically e-mailed to you upon receipt of your order. You can also check our Educational Orders FAQ.
Novedge does not provide technical support for educational versions of the software. If you need technical support please refer to the manufacturer website for additional information.
Latest Mesh2Surface Webinars from Novedge
Novedge Webinar #304: From Scan to CAD: 3D Reverse engineering with Mesh2Surface
