InnoDraw combines laser technology and powerful software together with many years of experience to create the most innovative measuring system available for your needs. It creates complete 2D and 3D remodeling or construction, detailed drawings, right at the job site! Drawings are then automatically converted – via the InnoDraw cloud-based server – to your design program’s format: 2020, AutoCAD, Cabinet Vision, SketchUp, Raumplan, Promob, and more.
Customized software in combination with extremely accurate laser measuring devices, provide the ultimate solution for a variety of projects. InnoDraw’s measuring technology can be applied to every part of the construction and remodeling industry including but not limited to:
Create detailed 3D measurements a using hand-held, Laser Distance Meter LDM
InnoDraw’s Elcad Software runs on Android with a handheld laser device.
Measuring laser range - The basis of the hardware system is a laser-based rangefinder. The device sends laser signals to objects (walls, outlets, windows, etc.) and according to the signal returned it calculates the distance and the angle from the device to the object.
Software - At the end of the process, the software connects all the data into a perfect electronic drawing in InnoDraw’s unique format – called ELC.
Digital Mapping - Further to the measuring process, data of other objects can be added, and an accurate map of the total area is created by the computer. The system allows different types of measuring. For example: The system allows the surveyor to verify the accuracy of the measuring by making “check and verification measurements” where the computer – according to the calculated internal map – validates the data of the verification checks. - Straight wall: The surveyor aims at two random dots and the system calculates the straight line which is the wall. - Curved wall – the surveyor aims at several points along the wall and the system draws the exact “curvature” (profile) of the wall. The system allows the surveyor to verify the accuracy of the measuring by making “check and verification measurements” where the computer – according to the calculated internal map – validates the data of the verification checks.
Friendly interface - The surveyor has many drawing tools at his disposal activated by screen touch. During the regular measuring process, the surveyor does not need to give any instructions to the computer. All he needs to do is to aim the laser beam and “scan” the walls. The computer follows the laser beam position and completes the mapping. Once mapping is finished, the surveyor can use the many tools at his disposal to add relevant information to complete the overall drawing.
Cloud access - Upon completion of the measurement, the surveyor presses a button and transmits the drawing to the InnoDraw server. The measuring information is automatically registered on the server. In addition, the server converts the drawing format to the specific format required by the user, such as PDF, DXF, DWG, ORD, etc. The drawing in its final format is sent to the user. In addition, an email is sent to the user, advising him that the measuring has been carried out and is available at his personal site, opened for him by InnoDraw.
