DraftSight Professional - Subscription

SKU: 19343
MPN:---------
UPC:---------
Subscription
Dassault Systemes | DraftSight Professional - Subscription
Options
17

Essential 2D design and drafting with a complete set of edit, design and automation tools.

- Advanced 2D Design
- Productivity Tools
- API Access
- And much more

Dassault Systemes
Authorized Reseller

$249

As low as $23.03/month with CreditKey CreditKey
Ask for Quote
Talk to our Experts
866 362 8970

Digital
Delivery

Product download information and license key delivered via EMail

Available
in USA

Best Price
Guarantee

Prorated Licenses, Flexible Payments, Custom Orders

Overview


DraftSight Professional is the best in class 2D CAD with powerful productivity tools and an API to accelerate your design projects.
Create, view, edit and convert drawings including DWG, DXF, and DGN files.

  • Draw fundamental elements such as lines, polylines, arcs, circles, ellipses, tables, hatches, and clouds
  • Convert raster images like floor plans and logos to vectorized entities in seconds
  • Import, create, and manage layers, blocks, and external references, and output drawings to a plotter, printer, or file
  • Comprehensive API to customize and automate processes using LISP, C#, C++, VB or similar programming languages


Highlights

  • Advanced 2D Design - Feature-rich 2D CAD solution. Streamline the design process, continue to use your favorite tools while increasing efficiency. Easy to get started.
  • Productivity Tools - Robust productivity tools, including support for Dynamic Blocks, PowerTrim, DrawCompare, and automatic layer assignment.
  • API Access - A robust API to customize and automate processes with LISP routines or your favorite programming language.


Top Features
Image Tracer
Convert raster images in .bmp, .png, and .jpg formats into accurate and editable lines and curves in DWG files. The images can range widely from floor plans to artistic logos saving massive time and tedious effort to manually retrieve and edit the image elements.		 Layers Manager
Manage and organize layers easily and consistently. Show, freeze, lock layers, or modify layer styles at one single location to carry out changes at scale and speed up your drafting process.		 Dynamic Block Support
DraftSight supports viewing and manipulating AutoCAD® Dynamic Blocks. The special grips allow you to change size, shape, orientation, or even choose how a block is displayed among multiple variations carried over from your legacy drawings.

Mechanical Toolbox
DraftSight contains robust mechanical tools and symbols that will help you standardize your mechanical drafting practices and speed up your time to market. The Mechanical Toolbox allows you to choose which industry-standard you want to use or create your own custom standard.		 Visual LISP
Run Visual LISP routines directly in addition to DraftSight’s existing support of AutoLISP.		 Draw Compare
Compare drawing revisions to quickly identify and track changes. Draw Compare will graphically depict differences between drawings or show entities that have been added or removed in the color of your choice.

Mouse Gestures
Access your most frequently used commands by simply holding down the right mouse button and moving the mouse in the proper direction to access commands and speed up drafting.		 Auto Dimension
Use the AutoDimension command to dimension drawings automatically. Create baseline, continued, and ordinate dimensions for specified entries that are enclosed within a Dimension Bounding Box.		 PowerTrim
PowerTrim cuts to the chase by assuming everything is a cutting edge from the get-go. Just start the PowerTrim command and drag your cursor over the entities you want to trim. That’s it! No more selecting cutting edges, you just start trimming.

LISP Automation
DraftSight makes it easy to load and use your favorite LISP code, including AutoLISP® and Visual LISP® to automate tedious or repetitive tasks.
Customize with APIs
DraftSight provides extensive APIs for you to build custom capabilities to fit your specific needs. In addition to LISP based automations, you can also load Dynamic Link Libraries (.dll files) or custom scripts.
