Overview
Cyborg3D SubD2CAD brings the powerful SubD to CAD conversion tools (found in nPower's Power Surfacing add-in for SolidWorks and Power SubD-NURBS plug- in for MODO) to the rest of the Sub-D design community. SubD2CAD is a standalone product that can be used to convert existing subdivision surface models into NURBS boundary representations (Breps) which may be exported to standard formats readable by all CAD systems.
Highlights
- Bring your subdivision surface models into a CAD system
- Convert Z-Brush sculptures into CAD readable formats
- Import polygonal models from Turbosquid or other polygonal model sites into your CAD software package
- Make organic shapes quickly and easily
Supported Workflows
- Import, modify and convert a "Catmul Clark" subdivision surface (from SubD design programs, or from a model repository like Turbosquid.com) to a CAD format.
- Import and convert high resolution (up to 6 million polygons) sculpted quadrilateral meshes from ZBrush or other sculpting packages.
- Import, repair, shrink wrap with a quadrilateral mesh and convert high density triangular scanned meshes.
- Design SubD models directly inside of SubD2CAD and then convert to a CAD format.
Tutorials
|
|
|
|
|
|
| Modeling a gas can | Brep to SubD command | Turbosquid workflow | Modeling a spoon | Converting ZBrush sculptures |
