Home / CrossGems / CrossGems Pro

CrossGems Pro

SKU: 19534
MPN:---------
UPC:---------
Perpetual License
CrossGems | CrossGems Pro
Options
466

The ultimate software made for designers.
Explore new possibilities in the jewelry's world.
A Rhino and Grasshopper jewelry plug-in.

CrossGems
Authorized Reseller

$2,743

As low as $253.73/month with CreditKey CreditKey
Ask for Quote
Talk to our Experts
866 362 8970

Digital
Delivery

Product download information and license key delivered via EMail

Available
in USA

Best Price
Guarantee

Prorated Licenses, Flexible Payments, Custom Orders


Ready to Cross


CrossGems is a Rhinoceros 7.0 & Grasshopper jewelry plugin with standalone UI.

With more than 100 tools at your disposal and an accurate history manager, you will enjoy the design of powerful parametric models in a comfortable and easy way using the CrossGems UI, the Rhino UI or Grasshopper.



Highlights


Remove Boolean Holes
Manage your boolean operations easily from the history panel, removing cutters, holes or any object used in a boolean difference, and keeping the full model parametric.

100% Parametric Tools
CrossGems tools are 100% parametric for Rhino and Grasshopper, furthermore it can be combined with Rhino History thus offering endless design possibilities

 Intuitive Powerful User interface
CrossGems UI is a standalone modern and clean standalone UI interface optimizing space and making the software intuitive being ergonomic in everyday use.

Fast & Reusable Design
The models can be reused due to the implemented parametric design that provides a reduction of time in the workload when you are modifying any design and exploring all the possibilities that arise. 		Compatibility
CrossGems is able to read and edit gems from others softwares like Matrix, RhinoGold and Panther, furthermore it has full compatibility with Panther models keeping the model 100% parametric. 		Gallery Presets
This feature allows to store builder parameters to match any other target gems, rings and other objects, store your own presets or use one of the predefined presets which the software includes. 		Integrated Render Material Library
The integrated material library allows to set and change metal, gem or ground materials just with few clicks, its automatic conversion by Display Mode will change materials in real time to adapt them for every rendering state.

Features

  • Accurate Stone Setting Tools - Multiple Gem settings available to create sets for any stone. With CrossGems you can rely on precision stone setting without compromising the design needs. Each unique Gem deserves a custom set.
  • Advanced Jewelry Builders - Creating models from scratch or starting from interactive gallery parts. Each builder offers unique options for every detail of the design. The modelling history comes automatic on a logic modelling process.
  • Sub Division - Newly integrated with Rhino 7.0 - SubD tools allows organic modelling for pieces which require smooth details.
  • Automatic Pave - The most advanced Pave tool supports Nurbs, SubD and Mesh objects for gems placement. Each step of the design is saved, enabling you to make any further adjustments and updating all the steps saved in real time. This is a huge time saving creating or changing designs.
  • Gallery Parts - Each builder can be defined from scratch or even starting from the gallery where sample parts are available to start from. The possibility to save your custom gallery parts is also available, providing the opportunity to fully customize your gallery.
  • Automatic Patterns - Patterns are the faster way to create high volume jewelry parts with a small amount of metal. Either using patterns from the gallery or adding your own ones, there are several controls to accomodate them on each piece.
  • Automatic Integrated Render - The integrated render and materials allow to create photo-realistic images in a very simple way, CrossGems will automatically manage the model materials when the display mode is switched.



Compare


Which version of CrossGems if right for you?


CrossGems is available on Rhino as a plug-in and in Grasshopper as an add-on for both available versions.
Choose the one that better fit your needs to design!

Tools

 CrossGems Lite

 CrossGems Pro
Gems
Gems - Creates a Gem by Cut, Size and position ✔ ✔
Cabochon - Loads a Cabochon Gem by defining the shape, Size and position ✔ ✔
Mixed Gem Cut - Loads a Mixed Gem Cut defining the shape, Size and position ✔
Gems on Curve - Creates Gems along a curve with multiple possibilities to modify the size and position. ✔ ✔
Pave - The most advanced Pave tool supports Nurbs, SubD and Mesh objects for gems placement. ✔ ✔
Gem on Ring - Places a Gem on a Ring defined by several controls ✔ ✔
Trilogy - Defines the 3 stone ring with the Gems oriented on the ring rail ✔ ✔
Offset Gem Curve - Defines the 3 stone ring with the Gems oriented on the ring rail ✔ ✔
Move Gems - Move the gems on the normal direction ✔ ✔
Copy to Gems - Match an object from one Gem to another ✔ ✔
Flip Gems - Flip any gem selected ✔ ✔
Gem Info - Detailed information about the gems with the option to export as PDF ✔ ✔
Settings
Head - Creates a Head Set based on a Gem input ✔ ✔
Bezel - Creates a Bezel Set based on a Gem input ✔ ✔
Claw - Defines a Claw Setting based on a given Gem ✔ ✔
Calotte - Creates a Calotte Setting based on a Gem input ✔ ✔
Under Bezel - Creates an Under Bezel or Gallery Rail based on a Gem input ✔ ✔
Halo - Creates a Halo with gems around a given Central Gem ✔ ✔
Prongs Row - Creates a Prong Set, Bar Set or Bridges on a given Gems row ✔ ✔
Pave Prongs - Creates a prong set on a given gem of a pave ✔ ✔
Prongs on Gem - Creates Prongs on a given Gem ✔ ✔
Prongs on Object - Creates a prong on a given object ✔ ✔
Micro Cluster - Creates a Cluster with Gems following adjustable settings ✔ ✔
Jewelry
Bail - Loads a customizable Bail defined by controls ✔ ✔
Bead - Creates a standard Bead customizable by several controls ✔ ✔
Charm - Creates a customized Charm defined by several controls ✔ ✔
Hoops - Loads Hoop Earrings which can be customized by several controls ✔
Bangle - Loads a Bangle or Cuff defined by options to control ✔ ✔
Quad Ellipsoid - Loads a Quad Ellipsoid defined by options to control ✔ ✔
Earring Post - Loads an Earring Post which can be customized by several controls ✔ ✔
Snail - Loads a metal Snail defined by customized controls ✔
Chain - Loads a Chain which can be customized by several options ✔ ✔
Ornaments on Curve - Creates Ornaments along a curve defined by input controls ✔ ✔
Millgrain - Creates a Millgrain along a curve defined by customizable controls ✔ ✔
Metal on Curve - Creates a shape along a curve defined by profiles controls ✔
Rope - Creates a Rope along a curve defined by several options to control ✔ ✔
Filigree - Defines a Filigree shape along a curve defined by customizable controls ✔ ✔
Auto Pattern - Creates a Pattern along a given surface defined by controls. Includes many patterns to start from ✔ ✔
Auto Voronoi - Creates a Voronoi Pattern along a surface defined by several controls ✔
Texture - Creates a texture on a given surface based on a grayscale image ✔ ✔
Auto Squish - Creates Jali patterns from gallery on given objects ✔ ✔
Texture - Creates a texture on a given surface based on a grayscale image ✔ ✔
Cutters
Gem Cutter - Creates a Gem Cutter for the pilot hole from any given Gems ✔ ✔
Channel Cutter - Creates a Channel Cutter along a Gems Row defined by Controls ✔ ✔
Cross Cutters - Creates Cross Cutters around a given Gem, also known as Scallop cut ✔
Micro Cutters - Defines Micro Cutters along a given Gems Row, idial for Fishtail style ✔ ✔
Bright Cut - Creates a Bright Cutter based on a Gem input ✔ ✔
Azure Cutter - Creates Azure Cutters on the bottom of the Gems ✔
Hollow Ring - Hollow out a solid ring on the inner part defining the wall thickness and multiple under gallery options ✔ ✔
Cut to Ring - Cuts a given object by the inner part of the ring size curve ✔
Hinge - Defines a Hinge articulation on a given Object ✔
Recess - Defines a recessed area on a given Object from a projected curve ✔ ✔
Auto Cut - Cuts an object with a planar curve ✔ ✔
Planar Cutter - Creates 3 axis Planar Cutters on a given Object ✔ ✔
Rings
Shank - Defines a Basic Shank which can be further customized by various controls ✔ ✔
Cathedral - Creates a standard Bead customizable by several controls ✔ ✔
Bombe - Creates a customized Charm defined by several controls ✔ ✔
Signet - Loads Hoop Earrings which can be customized by several controls ✔ ✔
Split Cathedral - Loads a Bangle or Cuff defined by options to control ✔
Eternity Band - Loads a Quad Ellipsoid defined by options to control ✔ ✔
Shaped Ring - Loads an Earring Post which can be customized by several controls ✔ ✔
Braid Ring - Loads a metal Snail defined by customized controls ✔
Round Bypass - Loads a Chain which can be customized by several options ✔
Criss Cross - Creates Ornaments along a curve defined by input controls ✔
Infinity Shank - Creates a Millgrain along a curve defined by customizable controls ✔ ✔
Band - Creates a shape along a curve defined by profiles controls ✔ ✔
Split Shank - Creates a Rope along a curve defined by several options to control ✔ ✔
Bypass Ring - Defines a Filigree shape along a curve defined by customizable controls ✔ ✔
Twin Shank - Creates a Pattern along a given surface defined by controls. Includes many patterns to start from ✔
Ring Rail - Creates Jali patterns from gallery on given objects ✔ ✔
Outside Ring Rail - Creates a Voronoi Pattern along a surface defined by several controls ✔ ✔
Tools
Profile Placer - Places a Profile on a curve or along 2 rails. Will follow any further curve changes ✔ ✔
Auto Sweep - Sweep 1 Rail or 2 Rails with parametric history ✔ ✔
Mirror - Creates a mirror in the oposite axis of x/y/z and diagonal ✔ ✔
Polar Array - Creates circular copies from given objects with possibility to interpolate and more ✔ ✔
Smooth Cap - Creates a rounded cap shape based on a profile curve ✔ ✔
Cross Section - Creates a isocurve of axis x/y/z on the objects or polysurfaces ✔ ✔
Section From Ring - Captures the curve sections from a given ring ✔ ✔
Curve on Ring Rail - Creates a curve in the ring rail that can be modified by size and diameter ✔
Profile Blend - Creates a soft shape between two profiles with a set of options to be modified ✔ ✔
Flow on Surface - Defines a flat surface referenced on a given one to flow objects along ✔
Extract Surface - Extracts a Surface from an Object, will auto update any changes on the given object ✔ ✔
Move Away - Creates a shape along a curve defined by profiles controls ✔ ✔
Text on Curve - Creates a Text along a given curve with multiple control options ✔ ✔
Booleans ✔ ✔
Cap - Closes a given object with flat caps on planar holes. Also will follow the History of the given objects ✔ ✔
Slicer - Create section curves from the object defined by number or distance ✔ ✔
Join - Join connects objects together to form a single object ✔ ✔
Curve From 2 Views - Creates a curve from two curves that are planar in different construction planes. ✔ ✔
Isocurve - Creates a curve of constant u- or v- value on a surface ✔ ✔
Rasterize - Raster the curves from a given image ✔ ✔
Autoextrude - Creates an open or closed shape from a curve or base surface ✔ ✔
Object on Curve - Creates a copy of the object selected on a curve with the options of translate, rotate, and move ✔
SubD
SubD Shank ✔ ✔
SubD Signet ✔ ✔
SubD Ring ✔ ✔
SubD Bezel ✔ ✔
