Annotation Convertor (AC) – Automatically converts drawing dimensions & notes to 3D annotations
Assembly Collapse Configurator (ACC) – Recreates representations as Simplified-Reps and Explode States in Creo (specifically from converted Accu-Trans assemblies)
Benefits and capabilities
Current migration methods lose associativity between the model and drawing and are painstakingly manual in nature. Associativity between transferred models and drawing is often missing. With LMX you will have a smooth transition to improved productivity.
The LDA The Legacy Drawing Associator provides three levels of association: Model > View > Annotation. And it works on any data retrievable by Creo: STEP, IGES, Mapped, DXF*, others….
No more manually searching for the model to map
Re-linked model & drawing retain their association when checked into PDMLink
Future model changes are immediately reflected in the drawing
The LDA takes care of recreating & placing views
Witness line attachment to model means model changes are reflected in drawing dimensions
LDA allows control of how dimensions are displayed to meet specific company requirements
