CAD Files Converter

SKU: 15915
MPN:---------
UPC:---------
Perpetual License
VisionWorkplace | CAD Files Converter
Options
12

Convert your CAD files to other file formats

VisionWorkplace
Authorized Reseller

$99

As low as $9.16/month with CreditKey CreditKey
Ask for Quote
Talk to our Experts
866 362 8970

Digital
Delivery

Product download information and license key delivered via EMail

Available
in USA

Best Price
Guarantee

Prorated Licenses, Flexible Payments, Custom Orders

CAD Files Converter is a standalone application that can convert your CAD files/models to other 3D file formats.

Below are the supported formats in this version.
Input format: 1) FBX
Output format: 1) OBJ 2) 3D PDF 3) DXF 4) DAE

How to use this standalone application

1. Download and Install the program
2. Open "CAD Converter" shortcut Icon from your desktop, or open your installed Directory, default: "C:\Program Files\CAD Converter" and launch "CADConverter.exe" from this folder.
3. Browse your CAD files. Currently supported FBX file as an input
4. Select conversion format, like OBJ, 3D PDF etc. and "Start Conversation"

Convert Autodesk Revit Files to 3D PDF, OBJ, DXF and DAE
1. In Revit, open a 3D view, and prepare it for export.
2. Click Export (FBX).
3. In the Export 3ds Max (FBX) dialog, for Save in, navigate to the target folder for the exported file.
4. Choose options based on your need
5. Click Save.

Convert Autodesk AutoCAD Files to 3D PDF, OBJ, DXF and DAE
1. Click Application menu -> Export FBX.
2. In the FBX Export dialog box, specify a name and location for the file and click Save.
3. The FBX Export Options dialog box displays. Specify the items to export, the texture options, and click OK.

Convert Autodesk Navisworks Files to 3D PDF , OBJ, DXF and DAE
1. In Autodesk Navisworks application, click Output tab -> Export Scene panel -> FBX
2. Select the desired export options from the dialog
3. Click OK.
4. In the Export dialog box, enter a new filename and location, if you want to change from those suggested.
5. Click Save.
