ArCADia-DISTRIBUTION BOARDS 2

ArCADia Distribution Boards is an industry-specific module of the ArCADia BIM system, based on the ideology of Building Information Modeling (BIM). The program enables the development of the professional technical documentation required to produce single-line circuit diagrams. The program is designed both for designers of networks and electricity and power systems, as well as for all people working in the electrical engineering industry.

The ArCADia Distribution Boards program can be used to create a diagram of a designed switchgear or any circuit diagram and perform basic technical calculations. The library of electric device symbols can be used to design an electrical system. Symbols can be edited and assigned technical parameters.

This module expands the capabilities of the ArCADia BIM program with advanced functions, which means that part of the building modelling options are available in the ArCADia BIM program: ArCADia BIM LT, ArCADia BIM, ArCADia BIM PLUS.

Advanced features of the ArCADia-DISTRIBUTION BOARDS module

The quick and efficient design of single-line schematic diagrams for switchgears. Automatic generation of actual views of distribution boards. The possibility to create control systems.	The automatic generation of a distribution panel diagram designed using the ArCADia-ELECTRICAL INSTALLATIONS overlay.
A database of electric devices, instruments and electric device symbols (Cam switches, Frequency inverters, Softstarts, Fuses, Voltage coils).The expanded library of electrical equipment (Legrand, Moeller, Schneider, Hager, ABB, Jean Muller).	The possibility to create an actual view of a distribution board and to put in electric devices.
The preview of created distribution boards in a 3D view.
