Convert Large Navisworks files to 3DPDF with this plugin. 3D PDF Converter for Autodesk Navisworks supports to export different views of Navisworks model.
Convert Unit toGet converted file in specified measurement unit. Change the unit if you need to have output file in different unit than defaultFlip YZ-axisCheck this if need output for different co-ordinate systems.Do not Export Hidden EntitiesEnabling this checkbox will skip hidden parts and export only visible parts. Used when model is very large and you need to export only visible parts.Steady Conversion Flow (Navisworks specific)Check this option if Navisworks file size is very large and not able to convert with default conversion flow. Section box feature will not work while converting with this option.Pro Feature: Property CSVThis will export CSV file containing properties of model parts, the obj file will have unique "OBJ group id" which can be mapped to the CSV file.Pro Feature: Export in Separate OBJ FilesWhen model is very large and the software where you want to open OBJ is not capable of opening large OBJ file. Choose this option to export file in multiple OBJ files.Export Section Box (Navisworks specific)Enable SectionBox in Navisworks and export only visible section in output file. If you need to convert only specific part of the model to output file then enable SectionBox from Viewpoint->Sectioning (As per screenshot below), check this option and convert.Don't show at convertCheck if don't want to open this setting dialog every time.
Accuracy uptoHigher the accuracy, more fine the meshes and larger the file size. High accuracy will have more decimal points in verticesDetailingLower detailing will skip small entities to be converted in output file. When you need file size to be very small and do not need to have higher LOD model then keep detailing low. Default it should be full to output each and every entities of modelQualityThis is to control level of detail in the exported mesh.Level of DetailsThis is to control Quality. Same as above option. In some plugin Quality option is there and in some plugin LOD is available.Write NormalsWant to export normals as well in exported file.Reduce polygonReduce no of polygons. This option is not available in all plugins as of now.
Rendering TypeChoose rendering type you need in PDF. Like outlineLight TypeWhich light should be set to 3D PDF. Like CAD, Day etc.Include 3D ViewsThis will include 2d views in following page of 3D ModelBackground ColorSelect color which needs to be in 3D PDF Background
In trial period, we export only 20% Geometry's properties". In pro version we export properties of all geometry.
