ZBrush Tip: Tangent vs Object-Space Normal Maps in ZBrush

Picking between Tangent and Object space normals is a small checkbox in ZBrush that has big downstream implications. Choose based on how your asset moves, where it goes, and how your target renderer interprets normals.

• Tangent-space normals
  • Best for deforming assets like characters, creatures, and anything rigged. The detail “sticks” to the surface as it bends.
  • Produces bluish maps with subtle color shifts; orientation is relative to the surface tangent basis.
  • Portable across UV edits (as long as topology and tangents are preserved) and efficient for game engines.
  • Typical for engines like Unreal and Unity; verify channel orientation (often requires green-channel flip depending on target).
• Object-space normals
  • Ideal for static props, hero assets, scans, and product shots where the mesh won’t deform.
  • Produces colorful “rainbow” maps; orientation is relative to the object, yielding cleaner gradients and fewer shading artifacts.
  • Great for baking ultra-clean hard-surface details and for offline renders where stability and fidelity matter.
  • Not suited for deformation; any pose change breaks lighting correctness.

Configuring in ZBrush

• Prepare UVs first (Tool > UV Map). Set the final map size (e.g., 4096) and enable SmoothUV if your destination smooths during render.
• Create normals (Tool > Normal Map):
  • Enable Tangent for tangent-space, disable it for object-space.
  • Flip G if your target uses DirectX-style normals; uncheck for OpenGL conventions. Verify per engine.
  • Use Adaptive for sharper microdetail on hard surfaces; test with and without to avoid aliasing.
• For multi-subtool or batch export, use Zplugin > Multi Map Exporter. Match size, padding (8–16 px), and channel flips consistently.

Pipeline and compatibility tips

• Match tangent basis with your destination. If your engine/DCC uses MikkTSpace, confirm results in-engine; when absolute parity is required, consider baking in the target app for 1:1 shading.
• Avoid double flips. If you flip G in ZBrush, don’t flip again on import. Keep a per-engine preset.
• Set normal maps to non-color data (linear) in external DCCs and engines to prevent gamma shifts.
• Mind UV seams: enable padding and, if needed, SmoothUV to align with the renderer’s smoothing behavior.
• Validate with a neutral lit turntable before committing. Look for seam pops, inverted curvature, or gradient banding.

Quick decision checklist

• Is the asset deforming? Use Tangent.
• Is the asset static and needs pristine shading? Use Object.
• What’s the engine convention? Set Flip G accordingly.
• Are UVs final and padded? Prevent seam artifacts.
