Pipe flange part 2: Secondary flange with imported bolts and nuts | Modeling projects

Video From YouTube: Shapr3D




Continuing the journey into flange modeling, this informative tutorial guides viewers through advanced techniques in creating a secondary pipe flange using Shapr3D. The expert mechanical engineer, Gabe Corbett, presents a step-by-step process on importing and incorporating bolts and nuts into the design. Key focus areas include setting up sketches for construction geometry, utilizing planes for accurate mirroring, and alignment of components. Viewers will gain a thorough understanding of the mirror tool and other Shapr3D functionalities to ensure efficient modeling practices. This video is perfect for those looking to enhance their CAD skills and streamline their design workflow.

If you like this content please subscribe to the Shapr3D YouTube Channel
