MCP Alignment and Profiles | tcpMDT 26

Video From YouTube: aplitop




This video provides a detailed walkthrough on working with alignments and profiles using the MCP feature in tcpMDT 26 by aplitop. It demonstrates the seamless integration with Claude Desktop for natural language interaction. Beginning with a drawing that contains a predefined alignment, the video illustrates how to utilize the assistant to describe the alignments present in the document. Viewers are guided through the process of selecting the option to create a longitudinal profile, incorporating the current alignment and surface. The tutorial concludes with guidance on setting horizontal and vertical scales, enabling the updated drawing to display the generated profile accurately.

If you like this content please subscribe to the aplitop YouTube Channel
