December 27, 2023 3 min read
DraftSight is a feature-rich 2D and 3D CAD solution for architects, engineers, and construction service providers, as well as professional CAD users, designers, educators, and hobbyists. More efficiency and faster completion of tasks in the CAD environment are often achieved through customizing the user experience and automating repetitive tasks.
Among the customizable elements in DraftSight, Custom Blocks with mirroring capabilities stand out for their ability to streamline drawing and editing processes. Custom Blocks in DraftSight allow for dynamic adjustment of blocks within your drawing, providing a more efficient way to manage repetitive elements that come in various configurations. By incorporating mirroring capabilities into Custom Blocks, DraftSight users can instantly flip or mirror parts of their blocks horizontally or vertically, which is particularly useful for symmetrical components or when adjustments to the orientation are needed. Creating a mirror activity in DraftSight involves defining an axis to mirror the block entities around. A vertical or horizontal flip can be added to a standard plan view door block, for example, enabling the user to quickly adjust the door's orientation without the need to redraw the component manually. To start, one simply right-clicks on the block and selects 'Edit Block' from the context menu, which opens the Block Editor. In this specialized environment, distinct from the main drawing space, users can find all the necessary tools under the 'Edit Block' ribbon tab. Adding a mirroring element is accomplished through the 'Element' dropdown in the ribbon, specifically selecting the 'Mirror' option. The user is then prompted to define the base point of the mirror axis and the endpoint, effectively creating the axis about which the block will mirror. Once the axis is established, a label for the grip can be set to aid future edits, and a grip count must be specified. The default grip count of one allows for an interactive grip to appear on the block, which users can drag to trigger the mirroring action. Subsequent steps involve associating the defined element with a mirror activity, selecting it within the 'Activities' panel, and choosing the entities within the block that the mirroring will affect. After the selection set is confirmed, the Custom Block is ready for the mirroring functionality to be tested. Testing the Custom Block is crucial to ensure that the mirroring activity functions as intended. DraftSight offers a 'Test Block' feature, accessible from the ribbon, that allows users to evaluate the custom controls within a simulated environment. Upon successful testing, the block can be saved and incorporated into the working drawing. Mirroring elements within Custom Blocks can greatly enhance the efficiency of drawing tasks. It eliminates the redundant work of creating multiple block variations for different orientations and simplifies modifications to existing block instances within a drawing. DraftSight users seeking to expand their capabilities further can look into compatible plugins and extensions such as AutoCAD, MAXON, and Enscape, available at NOVEDGE, which can complement and enhance the DraftSight experience by offering additional tools and functionalities tailored to specific industry needs. In conclusion, DraftSight's capability to create Custom Blocks with mirroring activities is a testament to its versatility and user-oriented design. It provides users with tools to streamline their workflow, saving time and increasing productivity. For those interested in exploring the most advanced design software technology and seeking personalized advice on the best solutions for their specific needs, contacting the sales team at NOVEDGE is highly recommended. NOVEDGE's extensive catalog includes the latest and most sophisticated design software, ensuring that professionals across various industries can find the tools they need to succeed.
