AutoCAD Tip: Share Exact AutoCAD Views with SHAREVIEW or Named View Exports

Sharing exactly what you see—zoom, layer state, visual style, and annotations—saves time and avoids miscommunication. Two reliable approaches in AutoCAD are cloud “snapshots” for quick reviews and exporting Named Views for formal deliverables.

Method 1: Share a cloud snapshot with SHAREVIEW (fastest review loop)

• Prepare your view:
  • Set the desired UCS, visual style, and annotation scale.
  • Clean up display: use LAYISO/VP Freeze for clarity and REGEN if needed.
• Optional: Create a Named View first (VIEW) and enable “Save layer snapshot” and “Save UCS with view” for repeatability.
• Run SHAREVIEW:
  • Choose Model, Layouts, or specific Named Views to include.
  • AutoCAD uploads a read-only snapshot to Autodesk Viewer and returns a shareable link.
• Distribute the link:
  • Recipients open it in a browser—no software required.
  • They can pan/zoom, toggle layers (when available), comment, and mark up.
  • Comments sync back into AutoCAD’s Shared Views palette for you to act on.
• Best for: quick internal/external reviews, RFI clarifications, and redlines without sending the DWG.

Method 2: Export Named Views to DWF/PDF with bookmarks (formal packages)

• Create robust Named Views (VIEW):
  • Use descriptive names (e.g., A101_Stair01, M201-RTU-Plan).
  • Enable “Save layer snapshot” and “Save UCS with view” to preserve visibility and orientation.
• Place views on sheets (optional but powerful):
  • On a Layout, use Insert View to drop Named Views as locked viewports at the correct scale.
  • Control per-viewport layers with VP Freeze for clean documentation.
• Export with navigable bookmarks:
  • PDF: Choose DWG To PDF, then PDF Options > enable bookmarks from Named Views and Layouts.
  • DWF: Use Export or Publish to include Named Views, creating easy navigation in Design Review.
  • Recipients jump directly to each view via bookmarks, ensuring consistency with your setup.
• Best for: RFQs, formal submittals, client packages, and archives that must mirror your on-screen configuration.

Practical tips for reliable view sharing

• Standards:
  • Adopt a view-naming convention tied to sheet numbers and disciplines.
  • Use Sheet Set Manager for consistent scales and batch publishing.
• Graphics:
  • Lock viewport scales; use PSLTSCALE and LTSCALE correctly for plotted linetypes.
  • Use ANNOTATIVE objects to maintain text/dim size across views.
• Layers and Xrefs:
  • Enable VISRETAIN=1 so Xref layer states behave per drawing.
  • Capture per-viewport layer visibility with VP Freeze instead of creating duplicate layers.
• Housekeeping:
  • Use OVERKILL and PURGE to avoid bloat that can slow shared views or exports.
  • REGENALL before capture/export to prevent display artifacts.

When to choose which? Use SHAREVIEW for rapid, low-friction feedback and Named View exports for deliverables that must remain navigable, printable, and standards-compliant. Both reduce back-and-forth and ensure your audience sees precisely what you intend.
