Expert MoldbaseExtension allows users to quickly and accurately simulate the injection molding of plastic parts within Creo Parametric™. This tool allows designers to identify potential problems, optimize designs, and improve the manufacturability of their products.
Plastic part designers need immediate access to reliable and easy-to-understand analysis data to gain insights into manufacturability and to optimize part design. Failure to do so can result in costly mold reworks, excess material usage, mold debugging trials, and increased time to market for final products. The Creo Mold Analysis Extension allows users to quickly and accurately analyze and optimize designs that are manufactured by injection molding.
The capabilities within the Creo Mold Analysis Extension give analysts and designers deep insight into plastic flow behaviors. This powerful tool gives users the ability to run injection molding analyses for design verification and optimization within Creo Parametric, resulting in reduced mold re-engineering costs and late-cycle design changes.
Identify potential mold filling problems such as short shots, air traps, weld lines
Improve design quality, reduce manufacturing cycle times and rework of molds
Identify optimal injection locations to reduce cycle time and improve product appearance
Easily usable by a non-specialist without extensive knowledge of plastic analysis
Easily optimize molding conditions via design study with multiple analyses. Batch run is supported
Embedded within Creo Parametric: - Easy-to-use interface - No data translation between CAD, CAM, and CAE
Features and specifications
Intuitive, process-driven user interface embedded within Creo Parametric
Animation for the plastic injection fill process
Comprehensive database of common plastic materials
Automatically apply optimized process conditions according to the selected plastic material
Identifies optimal injection gate locations
Appropriate resolution for potential issues including: short shots, air traps, weld lines, hesitations
True 3D solid solver which provides more accurate results compared to 2.5D technology
Extensive analysis capabilities: - Melt Front Time - Air Trap - Weld Line - Sink Mark - Fill Pressure - Temperature - Center Temperature - Bulk Temperature - Moldability (Confidence of Fill) - Velocity Vector - Max. cooling Time - Max. Shear Rate - Max. Shear Stress - Frozen Layer Ratio - Volume Shrinkage - Material Orientation - Gate Contribution - Fiber Orientation
English, German, French, Italian, Spanish, Chinese (Simplified and Traditional), Japanese, Korean, and Russian.
In order to work properly, your copy ofPTC Creo Behavioral Modeling Extension1-Year Subscriptionrequires:
Manufacturer's system requirements are generally the bare minimum that you need to run the software and insufficient for effective and productive operation of the product.
Our suggested "real world" mid-range desktop system key specifications to properly runCreoare as follows:
CPU: Intel Core i7
Graphics Card: NVIDIA QUADRO RTX4000
Hard Drive: 1TB NVMe
Operating System: Windows 10 Pro
