Overview
Scan&Solve Pro for Rhino software for engineering analysis from Intact Solutions is based on a patented meshfree technology that liberates Finite Element Analysis (FEA) from the dependence on and limitations of meshing. The salient feature of the technology is separate handling and controls of geometric and physical computational models that are seamlessly combined at solution run time. Enjoy unprecedented flexibility in handling geometric errors, small features, complex boundary conditions, and interfaces, while maintaining most of the benefits of classical FEA. Scan&Solve Pro for Rhino requires a functional Windows installation of Rhino 6 or 7. |
Ease of Operation Within Rhino
To use Scan&Solve Pro for Rhino, simply follow these steps:
- Select the material (standard or custom)
- Apply the restraints
- Apply the new load types by selecting Body at the command line for body loads OR by selecting faces to load and specify torque
- Click Go
- View the results (strength, weakness, deformations)
- Click Report to generate web-ready reports
- Click Bake to save the deformed shape
Using Scan&Solve
Scan&Solve Pro for Rhino extends the power and simplicity of Scan&Solve for Rhino to bonded heterogeneous multi-material structures made of complex anisotropic materials such as wood, bent laminates, and composite structures.
Scan&Solve Pro for Rhino incorporates many other advanced features, including multiple simulation scenarios and improved layout. Scan&Solve Pro for Rhino is offered as an annual license that also comes with an (annual) license of Scan&Solve for Rhino.
|
|
|
| A simple tutorial on how to set up and run a simulation on Scan&Solve Pro. |
Simulate bonded assemblies of components |
|
|
|
| Simulation with more advanced materials. | How set up a Scan&Solve Pro multi-material simulation |
Features
For users of Rhino who share the vision of seamless integration between geometric design and physical simulation. Scan&Solve Pro for Rhino is a plugin that performs linear stress analysis on solid models constructed in or imported into Rhino. No meshing or conversions are required and no prior knowledge of analysis or finite elements is needed.
Scan&Solve Pro for Rhino features the following improvements over Scan&Solve for Rhino:
- Analyzing assemblies of components
- Wood materials
- Orthotropic materials such as fiber-reinforced composites
- Streamlined interface
- Contextual help
- Multiple simulation scenarios per document
- And more...
