Workflow: Reverse Engineering a Truck Wheel Cap from 3D Scan | QUICKSURFACE

August 28, 2026 1 min read

Autodesk Fusion 360

Video From YouTube: QUICKSURFACE




QuickSurface demonstrates a reverse‑engineering workflow that converts warped 3D scan data of a truck wheel cap into a clean, usable CAD model. The process compensates for deformation in the original part and includes scan alignment, selection of a nominal region, cross‑section extraction and creation of revolved geometry. Surface construction is combined with draft angle control, circular pattern generation, trimming, shelling and filleting to recreate form and function. Deviation analysis verifies accuracy while smaller design features are reconstructed and integrated. The workflow highlights practical strategies for handling imperfect scans and producing manufacturable models in QuickSurface. Provides efficient, repeatable, production ready techniques.

If you like this content please subscribe to the QuickSurface YouTube Channel
