Power Surfacing Studio: Gear Tutorial

Video From YouTube: nPower Software




This informative tutorial from Aplitop provides a detailed walkthrough of the CAD gear design workflow, enabling viewers to create mechanical parts from the ground up using fundamental sketching tools. The video demonstrates the process of establishing a new sketch to define the outer geometry of a gear. Key CAD modeling techniques are highlighted, including the effective use of the Fillet tool to create rounded edges and smooth transitions. Additionally, viewers will learn how to leverage the Circular Pattern function to efficiently replicate features around a central axis, enhancing their design skills in a practical and engaging manner.

If you like this content please subscribe to the Npower Software YouTube Channel
