Cinema 4D Tip: Production Polygon Optimization Checklist

Proactive polygon optimization keeps scenes responsive and render times under control. Use this checklist throughout production, not just before delivery.

  • Model lean from the start
    • Block with low‑segment primitives; only add segments where they affect the silhouette or deformation.
    • Use Subdivision Surface with edge creases/weights instead of adding multiple support loops.
    • Favor bevels with small widths over dense chamfers; bake micro‑bevels to normal maps when possible.
  • Tame generators and splines
    • Subdivision Surface: keep Editor Subdivisions low; raise only for final renders.
    • Sweep/Extrude/Lathe: set Intermediate Points to Adaptive with a sensible Angle/Max Length; avoid Uniform with tiny steps.
    • Volume Builder/Mesher: increase Voxel Size; dial up Adaptivity; limit Smoothing iterations.
  • Use instances and proxies
    • Prefer Multi‑Instance for MoGraph and repeated assets; switch to Render Instances when compatibility is needed.
    • For Redshift, keep heavy assets as proxies to minimize scene RAM and speed IPR.
  • Level of Detail (LOD)
    • Set up LOD objects to swap in lighter meshes based on distance for both viewport and renders.
    • Keep material variations consistent across LODs to avoid shading pops.
  • Reduce and retopologize intelligently
    • Polygon Reduction generator: preserve boundaries and UVs; restrict by Selection Tags to keep critical areas crisp.
    • Remesh for clean, even topology, then reduce; it often deforms and subdivides better than chaotic meshes.
    • Bake detail from high‑poly to normals/displacement; use baked maps on a lighter render mesh.
  • Shading over geometry
    • Prefer Normal/Roughness maps to fake micro‑detail; reserve displacement/tessellation for hero close‑ups.
    • Tune Phong/Normal Tag angles instead of adding control edges; use Phong Breaks selectively.
  • Deform where it matters
    • Isolate dense topology to deforming regions; keep static sections low‑poly with baked detail.
    • Limit Deformer and Generator effects to Selection sets to avoid subdividing the entire mesh.
  • Viewport and diagnostics
    • Enable viewport HUD statistics (poly/point/object counts) to monitor impact in real time.
    • Keep Editor Subdivision, Hair, and Cloner preview counts conservative; raise only when reviewing.
  • Clean and consolidate
    • Mesh > Commands > Optimize to weld strays and remove unused points/polys.
    • Align/Flip Normals to fix shading without adding geometry.
    • Connect Objects + Delete after booleans/volumes to collapse construction history and then reduce.
  • Export smart
    • Triangulate only at export (FBX/GLTF) and include normals to preserve shading; keep source files quad‑based.

Establish a poly budget per asset and enforce it via LOD and review gates. Small, continuous savings compound into dramatic performance gains.
