tcpMDT 25 Standard | Convert Plots from Drawing

May 05, 2025 1 min read

tcpMDT 25 Standard | Convert Plots from Drawing

Video From YouTube: aplitop




This informative video from aplitop demonstrates the process of creating plots from existing drawings using tcpMDT 25 Standard. The tutorial guides viewers through the use of the Convert Drawing command, which efficiently transforms elements from specified layers into plots, complete with boundaries and numbering. After confirming the dialog, users are provided with a comprehensive list of plots, allowing for easy viewing and editing of data for each individual plot. This video is ideal for those seeking to streamline their workflow and enhance their plotting capabilities with tcpMDT 25 Standard's advanced features.

If you like this content please subscribe to the aplitop YouTube Channel
